H C Verma solutions, Introduction to Physics, EXERCISES (1-10), Chapter-1, Concepts of Physics, Part-I

Introduction to Physics

EXERCISES (Q-1 to Q-10)

1. Find the dimensions of

(a) linear momentum,

(b) frequency and

(c) pressure.


ANSWER: (a) Linear momentum = mass x velocity

= mass x distance/time
→p = m*l/t

The dimension of mass = [M]

The dimension of velocity = [L/T] = [LT⁻¹]

Hence the dimensions of linear momentum,

[p] = [M]*[LT⁻¹] = [MLT⁻¹]


(b) Frequency = 1/Time period

→f = 1/T

The dimension of frequency [f] = [1/T] = [T⁻¹]


(c) Pressure = Force per unit area
→ P = Force/Area = Mass*acceleration/Area
The dimension of mass = [M]
The dimension of acceleration = [LT⁻²]
The dimension of area = [L²]
Hence the dimension of pressure,
[P] = [M]*[LT⁻²]/[L²] =[ML⁻¹T⁻²]






2. Find the dimensions of

(a) angular speed ⍵,

(b) angular acceleration α

(c) Torque Г and

(d) moment of inertia I.

Some of the equations involving these quantities are

⍵ = (θ₂-θ₁)/(t₂-t₁), α = (⍵₂-⍵₁)/(t₂-t₁),

Г = F*r and I = mr².

The symbols have standard meanings.


ANSWER: (a) Angular speed ⍵ = (θ₂ - θ₁)/(t₂ - t₁)

The dimension of [θ₂ - θ₁] =Dimension of angle which is dimensionless

The dimension of [t₂ - t₁] = Dimension of time =[T]

Hence [⍵] = 1/[T] = [T⁻¹]


(b) Angular acceleration α = (⍵₂ - ⍵₁)/(t₂ - t₁)           The dimension of (⍵₂ - ⍵₁) = The dimension of angular speed = [T⁻¹]

The dimension of (t₂ - t₁) = The dimension of time =[T]

Hence the dimension of angular acceleration,

[α] = [T⁻¹]/[T] = [T⁻²]


(c) Torque = Force *Arm (distance),

i.e. Г = F*r

The dimension of force [F] = mass*acceleration =[M]*[LT⁻²] =[MLT⁻²]
The dimension of arm, [r] = [L]
Hence the dimension of torque,
[Г] = [MLT⁻²]*[L] =[ML²T⁻²]

(d) The moment of inertia, I =mr²
The dimension of mass, [m] = [M]
The dimension of radius/distance, [r] = [L]
Hence the dimension of the moment of inertia,
[I] = [M]*[L]² =[ML²]





3. Find the dimensions of

(a) electric field E,

(b) magnetic field B and

(c) magnetic permeability µ₀.

The relevant equations are

F =qE, F = qvB, and B = µ₀I/2πa

where F is a force, q is a charge, v is speed, I is current, and a is distance.


ANSWER: (a) F = qE, hence

Electric field E = F/q

The dimension of force [F] = [MLT⁻²]

The dimension of charge, [q] = [TI]

{Since charge = current*time}

Hence the dimension of electric field,

[E] = [MLT⁻²]/[TI] = [MLT⁻³I⁻¹]


(b) Since F = qvB,

Magnetic field, B = F/qv

Now, [F] = [MLT⁻²]

[q] = [TI]

Speed, [v] = [LT⁻¹]

Hence the dimension of magnetic field,

[B] = [MLT⁻²]/[TI]*[LT⁻¹] = [MT⁻²I⁻¹]


(c) Given, B = µ₀I/2πa

→µ₀ =2πaB/I

The dimension of distance, [a] =[L]

The dimension of the magnetic field, [B] =[MT⁻²I⁻¹]

The dimension of current, [I] = [I], and π is dimensionless. Hence the dimension of magnetic permeability,

[µ₀] = [L][MT⁻²I⁻¹]/[I] =[MLT⁻²I⁻²]





4. Find the dimensions of

(a) electric dipole moment p and

(b) magnetic dipole moment M.

The defining equations are p = q.d, and M = IA

where d is distance, A is area, q is a charge and I is current.


ANSWER: (a) The electric dipole moment, p = q*d

The dimensions of charge, [q] =[TI]

The dimensions of distance, [d] =[L]

Hence the dimensions of electric dipole moment,

[p] = [TI][L] = [LTI]


(b) The magnetic dipole moment, M = IA

The dimension of the area, [A] =[L²]

Hence the dimensions of the magnetic dipole moment, [M] = [I][L²] =[L²I]





5. Find the dimensions of Planck's constant h from the equation E = h𝞶 where E is the energy and 𝞶 is the frequency.


ANSWER: Since E = h𝞶

→h = E/𝞶

Energy = Force*distance {same as work done}

→[E] = [MLT⁻²][L] =[ML²T⁻²]

The dimensions of frequency, [𝞶] = [T⁻¹]

Hence the dimensions of Planck's constant,

[h] = [ML²T⁻²]/[T⁻¹] = [ML²T⁻¹]






6. Find the dimensions of

(a) specific heat capacity c,

(b) the coefficient of linear expansion α and

(c) the gas constant R.

Some of the equations involving these quantities are

Q =mc(T₂-T₁), Lₜ = L₀[1+α(T₂-T₁)] and PV = nRT.


ANSWER: (a) Since Q = mc(T₂ - T₁)

→c = Q/m(T₂ - T₁)
The dimension of (T₂-T₁) = The dimension of temperature = [K]
The dimension of mass, [m] =[M]
The dimensions of heat, Q = the dimension of energy =[ML²T⁻²]
Hence the dimensions of specific heat capacity,
[c] = [ML²T⁻²]/[M][K] =[L²T⁻²K⁻¹]

(b) Since Lₜ = L₀ {1+α(T₂-T₁)}
→Lₜ - L₀ = L₀α(T₂-T₁)
→α = (Lₜ - L₀)/{L₀(T₂-T₁)}
The dimensions of (Lₜ-L₀) and L₀ = the dimensions of length =[L]
The dimensions of (T₂-T₁) = dimension of temperature =[K]
Hence the dimensions of the coefficient of linear expansion, [α] =[L]/[L][K] =[K⁻¹]


(c) Since PV = nRT

→R = PV/nT

The dimensions of pressure, [P] =Force/area =[MLT⁻²]/[L²] =[ML⁻¹T⁻²]

The dimensions of volume, [V] =[L³]

The dimensions of temperature, T = [K]

The dimensions of amount of gas, [n] = [(mol)]

Hence the dimensions of the gas constant,

[R] = [ML⁻¹T⁻²][L³]/[(mol)][K]

      =[ML²T⁻²K⁻¹(mol)⁻¹]





7. Taking force, length and time to be the fundamental quantities, find the dimensions of

(a) density,

(b) pressure

(c) momentum, and

(d) energy.


ANSWER:  Note that instead of mass, force is taken as a fundamental quantity. Hence, we shall express the mass in terms of force wherever it comes. For example, Force= mass*acceleration

→mass = Force/acceleration

(a) Density = mass per unit volume = mass/volume

                 = Force/(acceleration*volume)

 Dimension of force = [F]

 Dimensions of acceleration = [LT⁻²]
 Dimensions of volume = [L³]
Hence the dimensions of density = [F]/{[LT⁻²][L³]}
          =[FL⁻⁴T²]



(b) Pressure = Force/Area = [F]/[L²] =[FL⁻²]


(c) Momentum = Mass*velocity

     ={Force/(Acceleration)}*{Length/Time}

     ={[F]/[LT⁻²]}*{[L]/[T]}

     =[FL⁻¹T²]*[LT⁻¹]

     =[FT]

(d) Energy = Force*Distance =[F]*[L] =[FL]




8. Suppose the acceleration due to gravity at a place is 10 m/s². Find its value in cm/(minute)².


ANSWER: 1 m = 100 cm, and 1 s = 1/60 minute

Putting these in the units,

10 m/s² = 10*(100 cm)/(1/60 minute)²

             = 1000*60² cm/(minute)²

             = 1000*3600 cm/(minute)²

             = 3.6x10⁶ cm/(minute)²





9. The average speed of a snail is 0.020 miles/hour and that of a leopard is 70 miles/hour. Convert these speeds in SI units.


ANSWER: The SI unit of length is m (meter), and of time is s (seconds).

1 mile = 1.6 km = 1600 m, 1 hour = 3600 s

Hence 1 mile/hour = (1600 m)/(3600 s)
                            = 4/9 m/s
So, average speed of a snail = 0.020 miles/hour
= 0.020*4/9 m/s =0.08/9 m/s =0.00889 m/s
= 8.89x10⁻³ m/s


And the average speed of a leopard =70 miles/hour

=70*4/9 m/s =280/9 m/s =31.11 m/s






10. The height of the mercury column in a barometer in a Calcutta laboratory was recorded to be 75 cm. Calculate this pressure in SI and CGS units using the following data: Specific gravity of mercury = 13.6, Density of water = 10³ kg/m³, g = 9.8 m/s² at Calcutta. Pressure = hρg in usual symbols.


ANSWER: Here h = 75 cm =0.75 m

Density of mercury, ρ = specific gravity*Density of water =13.6*10³ kg/m³

g = 9.8 m/s²

Hence the pressure at the base of the mercury column  in SI units =hρg

=0.75*13.6x10³*9.8 N/m²

=99960 N/m²

≈100000 N/m²

=10x10⁴ N/m²


In CGS units, units of mass = g, length = cm and time = s. We know that 1 kg = 1000 g, 1 m = 100 cm.

Hence, 1 N =1 kg-m/s² = (1000 g)(100 cm)/s²
=10⁵ g-cm/s² =10⁵ dyne
So, 1 N/m² =(10⁵ dyne)/(100 cm)²
                 =10 dyne/cm²

So, in CGS units, pressure = 10x10⁴ N/m²

=10x10⁴*(10 dyne/cm²)
=10x10⁵ dyne/cm²

--------------------------------------------------------------
